   Multi-rotors Motors SUNNYSKY M8318 120KV Outrunner Brushless Motor for Plant Protection Drone
   Electric (Brushless) Motors & Accessories
SKU:  M8318-12
SUNNYSKY M8318 120KV Outrunner Brushless Motor for Plant Protection Drone
Customers rating.
Add To Wish List
Added:2016/10/08
Updated:2016/10/10
Follow Us on:


  Tags: SUNNYSKY  M8318  120KV  Outrunner  Brushless  Motor  for  Plant  Protection  Drone

Specifications:


SUNNYSKY  M8318 120KV Outrunner Brushless Motor for Plant Protection Drone


SpecificationsM8318
Stator Diameter83mm
Stator Thickness18mm
No.of Stator Arms36
No.of Stator Poles42
Motor Kv120
NO-Load Current(A/10V)1.3A
Motor Resistance37mΩ
Max Continuous Current64A/10S
Max Continuous Power2870W
Weight635g
Outside Diameter91.6mm
Shaft Diameter15mm
Body Length40mm
Overall Shaft Length40mm
Max Lipo Cell12S
ESC80A
Recommend Prop(inch)TM30*10.5


PropVoltsAmps Thrust(g)Watts (W)Efficiency
(g/W)
Full throttle under load temperature
(inch)(V)(A)g/W
TM30*10.544.40.750031.0816.0875161
1.5100066.615.015015
2.41500106.5614.0765766
3.52000155.412.8700129
4.72500208.6811.9800652
5.93000261.9611.4521301
7.33500324.1210.7984697
8.74000386.2810.3551828
10.24500452.889.936407
11.95000528.369.46324476
13.95500617.168.91178949
15.86000701.528.55285665
17.46500772.568.413586
19.57000865.88.08500809
21.77500963.487.78428198
2480001065.67.50750751
25.985001149.967.39156145
28.590001265.47.11237553
30.895001367.526.94688195
33.5100001487.46.72314105
38.8110001722.726.38525123
43.7120001940.286.18467438
50.5130002242.25.79787709
57.7140002561.885.46473683
64.6153002868.245.3342816580







Includes/Requires:
Includes:
1 x motor
1 x accessory bag
