   Electric (Brushless) Motors & Accessories Electric Brushless Motors - Inrunner LEOPARD 4082/1000KV 4-Poles Inrunner Brushless Motor LBP4082/3Y
SKU:  40823Y
LEOPARD 4082/1000KV 4-Poles Inrunner Brushless Motor LBP4082/3Y
Customers rating.
Add To Wish List
Follow Us on:

  Tags: Leopard  4-poles burshless motor  red leopard

★new design,four-pole rotor,the overall efficiency of more than 90%;

★extremely low temperature without additional heat sink can meet the vast majority of applications;

★compared to competitive products,lighter weight,higher torque;

★use of high-quality materials:aluminum alloy shell fine,high-quality magnetic steel,high temperature wire,imported high-quality bearings;

★rotor using special materials reinforced,high-speed operation under the non-burst phenomenon;

★good heat dissipation ,high overload capacity;

★Low electromagnetic interference;

★minimum required electrical maintenance;

★long life

Model: LBP4082/3Y
Max Amps: 78A
Lipo Cell: 5-13s
Max Power: 3500W
KV(RPM/Volt): 1000
Resistance: 0.0175
No-load Current : 1.1A
Diameter×Length (mm): Φ39.8×82
Mounting hole depth: 7mm
Length of extend Shaft : 20mm
Shaft Diameter (mm): Φ5.0
Weight: 485g
1 x motor
3 x bullet connectors
