FrSky RX8R PRO S.Bus Receiver
Customers rating.
Add To Wish List
Added:2020/12/15
Updated:2020/12/15
Follow Us on:


  Tags: FrSky  RX8R  PRO  S.Bus  Receiver

Features:
Overview:

An upgraded version based on the RX8R receiver, it has all the same features including redundancy. The Pro version has higher precision and lower latency. It’s deviation of PWM is reduced to 0.5us, and the delay of PWM output is 9ms less than that of the X8R in high speed mode. A feature that deserves mention is the decreased effect of interference caused by the ignition process.

Features:

Strong anti-interference performance in ignition process
Higher precision of PWM
Lower latency on the PWM output
Support redundancy function
Smart Port enabled and support telemetry data transmission
Specifications:

FrSky RX8R PRO S.Bus Receiver


Dimension: 46.3mm*26.6mm*14.2mm (L*W*H)
Weight: 14.8g
Numbers of Channels: 16CH(1~8CH PWM or 9~16CH PWM from conventional channel outputs, 1~16CH from SBUS port)
With RSSI Output on Board: Analog DC 0~3.3V
Operating Voltage Range: 3.5V~10V
Operating Current: 100mA@5V
Operating Range: full range (>1.5km)
Firmware Upgradeable
Servo Frame Rate: 9ms (HS—High Speed Mode)/18ms (FS—Normal Speed Mode)
Compatibility: FrSky transmitters/transmitter modules in D8/D16 mode
Includes/Requires:
Includes:
1 x receiver RX8R
