HOBBYWING Centrifugal Spary Nozzle HW 9L-Spray

Specifications

Compatible battery	12~18S
Spraying width	4~12m
Droplet granularity	35~500μm
Maximum flow rate	9L/min
Maximum power	500W (54V)
Rated flow rate	5L/min
Rated power	350W (54V)
Throttle stroke	1050-1950μs
Throttle stroke calibration	Not available
Control mode	PWM/CAN
Communication mode	CAN
Dimensions	97.875278.3mm(Unfolded) \ 97.827176.5mm(Folded)
Weight	495g
Wiring Order	Red--+, Black--GND Yellow--GND,Purple--Signal Blue--CAN High, Green--CAN Low
	*Due to measurement errors, the actual product shall prevail.
