   FPV/ Aerial Photography Video Glasses/ Monitors 5.8GHz Diversity Receiver 7 inch 800x480 LCD Monitor W/Light Shield RC-701 | All bands 32CH Edition
SKU:  RC-701
5.8GHz Diversity Receiver 7 inch 800x480 LCD Monitor W/Light Shield RC-701 | All bands 32CH Edition
Customers rating.
Manual:
Add To Wish List
Added:2013/09/18
Updated:2013/09/18
Follow Us on:


  Tags: FPV monitor  wireless monitor  diversity receiver FPV monitor

Features:
Looking for a monitor compatible with all your 5.8G transmitters of different bands? here come the one for all monitor, all bands 32 channel edition 5.8G receiver integrated monitor.

Features:
1. Built-in Dual Receiver Automatically for best reception Automatic Antenna Switching
2. Dual buffered AV outputs
3. Can receive 2 different channels at the same time
4. Not affect by 2.4GHz R/C Radios
5. AV Receiver with Diversity inputs
6. Small, light weight, durable
7. All bands, 32 channels edition, compatible with all 5.8G FPV devices currently available on market.



Specifications:

5.8GHz Diversity  Receiver 7 inch 800x480 LCD Monitor W/Light Shield RC-701 |All bands 32CH Edition


Specification:

1. Screen size:7”
2. Screen type: TFT LCD Screen/long life, LED backlight
3. Resolution: 800*480
4. Brightness: 450cd/m2
5. Contrast: 500:1
6. View Angle: 140/120degree (Horizontal/Vertical)
7. Working Voltage: DV 7-12V(center positive) or 11.1V Li-battery
8. Power Consumption: < 8w
9. Size: 180mm x 120mm x 23mm
10. Built-in 5.8Ghz Dual diversity receiver automatically for best reception
11. Built-in 2CH 5.8Ghz AV output and 1CH AV input
12. Support 9 languages menu selection
13. Working temperature: -10℃~+ 65 ℃


Includes/Requires:
Includes:
1 x monitor
1 x light shield
2 x 5.8G 2db antennas
1 x wire set


Comments:
This device is upgraded from 8ch to 32ch from 19th Sep., 2013.
