   Multi-rotors Kit & Frame Snapper6 65mm Micro FPV Racer Quadcopter (Flysky Receiver Edition)
SKU:  SAP6-FL
Snapper6 65mm Micro FPV Racer Quadcopter (Flysky Receiver Edition)
Customers rating.
Add To Wish List
Added:2018/05/22
Updated:2018/05/22

Follow Us on:


  Tags: Snapper6 65mm Micro FPV Racer Quadcopter drone whoop (Flysky Receiver Edition) 0603

  Features:

Features:
- Betaflight support , multi flight mode: ACRO/AIR/ANGLE
- Powerful Brushless motor and Smooth ESC
- CNC aluminum alloy propeller guard
- Betaflight OSD support ,easy to get RSSI , Voltage and other info from your goggles
- Adjust the settings and the PID of the flight controller via OSD
- Flysky version support both AFHDS and AFHDS-2A Protocol
  Specifications:

Snapper6 65mm Micro FPV Racer Quadcopter  (Flysky Receiver Edition)

Brand name: Happymodel
Item name: Snapper6 FPV racing Drone
Wheelbase: 65mm
Receiver: Compatible Frsky receiver / Compatible Flysky Receiver
Size: 81mm*81mm*36mm

Items Specifications
SE0603 19000KV brushless motor

Configu-ration: 9N12P
Stator diamter: 6mm
Stator length: 3mm
Shaft diameter: Φ0.8mm
Motor dimension(Dia.*Len): Φ9mm*15.5mm
Weight(g): 1.7g
No.of cells(Lipo): 1S

Crazybee F3 flight controller

Firmware: Betaflight_3.3.0_Crazybee
MCU: STM32F303CCT6 (72MHZ, 256K FLASH)
Sensor: MPU-6000(SPI connection)
Board size: 28.5 * 28.5MM
Board weight: 3.5g
Power supply: 1S battery input (DC 3.5-4.35V)
Built-in 5A(each) Blheli_S 4 in 1 ESC Dshot600 ready
Built-in Frsky receiver with telemetry (D8/D16 switchable)
Built-in Betaflight OSD (SPI Control)
Built-in Current meter Max 14A
Built-in 5V 0.8A BEC with LC filter
Built-in voltage detection
BLHELI_S pass-through ready
Heading LED ready

BLHeli_S 5A 4 in 1 ESC

Power supply: 1S LiPo/LiPo HV (4.2v/4.35v)
Current: 5A continuous peak 6A (3 seconds)
Support BLHeliSuite programmable
Factory firmware: O_L_5_REV16_6.HEX
Default protocol: DSHOT600

Flysky receiver version

SPI BUS receiver
Protocol: AFHDS and AFHDS-2A Switchable
Channels: 8ch(AFHDS) or 14ch(AFHDS-2A)
No ground interference (Transmitter and receiver 1m from the ground): 300m
Failsafe support

AIO Camera & VTX

Output power: 25mw
Frequency: 48CH
Input voltage: 3.3V 5.5V
Current consumption: 300mA(type)
Camera resolution: 700TVL
Field of view: 120°
Video format: NTSC
Antenna: RG178 antenna
Frequency: 5.8GHz 6 bands 48 channels
With raceband: 5474 5945 MHZ
Size: 13.9"12.0mm (L*W)
Weight: 3g


Features:
Betaflight support, multi flight mode: ACRO/AIR/ANGLE.
Powerful brushless motor and smooth ESC.
CNC aluminum alloy propeller guard.
Betaflight OSD support, easy to get RSSI, voltage and other info from your goggles.
Adjust the settings and the PID of the flight controller via OSD.
Flysky version support both AFHDS and AFHDS-2A Protocol Flysky transmitter.
Full telemetry function ready.
Head lights ready.
Camera angle adjustable.




  Includes/Requires:

Includes:
- 1 x Snapper 6 Frame
- 1 x Crazybee F3 FC (Flysky)
- 4 x SE0603 KV19000 Motor
- 1 x 31mm 3-blades propeller(4cw+4ccw)
- 1 x AIO Camera & VTX
- 1 x USB Lipo/LIHV Charger
- 1 x Propeller disassemble tool
- 1 x Screwdriver


Requires:
1 x 1S Lipo battery (recommended type: 450mah, 30C, size: about 60x18x7mm)


Battery is NOT included, we provided 2 compatible connectors with the kit.
