JC23 EVO 23CC 2-Stroke Gas/Petrol Engine
Customers rating.
Add To Wish List
Follow Us on:

  Tags: JC Engines  petrol engine  gasoline engine  JC-30EVO

- 2 Stroke air cooled single cylinder
- Walbro membrane pump carburetor with dual needles and manual choke
- Automatic advancing electronic ignition
Engine Parameter:

Engine type : 2—Stroke gasoline engine
   Bore × Stroke: 33.3mm × 27mm
   park plug: NGK CM6 or JC CM6
   Carburetor: Walbro special-designing vacuum pump diaphragm type duplex needle carburetor
   Max power : 3.5hp/9500rpm
   Practical running speed : 1100 - 9500rpm
   Net Weight : 980g (incoulding CDI and muffler)
   Ignition system : CDI battery ignition (battery voltage: 4.8v—6v)
   Grease oil ratio : 25-30:1 used during the break-in (the initial 2 working hours); 35-40:1 used after the break-in.
Screw propeller dimension : 16x8, 16x10, 17x8, 17x10, 18x8

* Spare parts for this engine are available for special ordering upon request, you can give us the part code and quantity via the help ticket system before we list those parts on our website.
