Hobbywing Platinum 80A Speed Control V5

Lithium Polymer (Li-poly) & Ni-Mh battery packs, battery chargers, Electric (Brushless) Motors, Electric Speed Controllers ( ESC ), Gyros, Electric Accessories etc.

Hobbywing Platinum 80A Speed Control V5

Specifications
Cont./Peak Current 80A/120A
Input Voltage 3-8S Lipo
BEC Output Switch Mode：5-12V & Cont. 8A，Peak 20A
Wires & Connectors
Input Wires Red-12AWG-100mm1/Black-12AWG-100mm1
Output Wires Black-14AWG-100mm3
Input Connectors No
Output Connecotors 3.5mm Gold Connectors (Female)
ESC Programing via
Transmitter Not Support
LED Program Card Not Support
LED Program Box Not Support
LCD Program Box Supported
OTA Programmer Supported
Program Port Separate Program Port
Firmware
Firmware Upgrade Supported
Telemetry Function
Mikado VBar；Futaba S.Bus2；etc.
Size & Weight
Size 60.533*17.6mm (without fan)
Weight 77.5g (with wires, no fan)
Application scope
325-420 class electric helicopter (main blade length 325-420mm),or fixed-wing

Includes:
1 x Hobbywing Platinum 80A Speed Control V5 ESC

Please explain:
Messages of this section are not monitored by HiModel, it is for review and discussion among customers only.

Upload Image:
(Up To 5 Files, only .jpg/.gif/.png files are accepted and sizes below 2MB for each)

Post as: Review Question

Select grade: star(s)

Anonymous: Yes No

Cont./Peak Current	80A/120A
Input Voltage	3-8S Lipo
BEC Output	Switch Mode：5-12V & Cont. 8A，Peak 20A

Input Wires	Red-12AWG-100mm1/Black-12AWG-100mm1
Output Wires	Black-14AWG-100mm*3
Input Connectors	No
Output Connecotors	3.5mm Gold Connectors (Female)

Transmitter	Not Support
LED Program Card	Not Support
LED Program Box	Not Support
LCD Program Box	Supported
OTA Programmer	Supported
Program Port	Separate Program Port

Size	60.53317.6mm (without fan)
Weight	77.5g (with wires, no fan)
