► High performance microprocessor brings out the best compatibility with all kinds of motors and the highest driving efficiency.
► Maximum motor speed: 210000 RPM (2 poles), 70000 RPM (6 poles), 35000 RPM (12 poles).
► 3 start modes: Normal / Soft / Very-Soft, compatible with fixed-wing aircraft and helicopter.
► Throttle range can be configured to be compatible with all transmitters currently available on market.
► Smooth, linear, quick and precise throttle response.
► Separate voltage regulator IC for microprocessor to get a better anti-jamming capability.
► Multiple protection features: Low-voltage cut-off protection / over-heat protection / throttle signal loss protection.
► The output of the built-in BEC is switchable by user programming (5.25V or 6.0V).
► With governor mode for helicopter.
► USB supported. The firmware of the ESC can be updated by the USB adapter.
► Several kinds of Program Cards are supported. Very easy to program the ESC at home or at the field.

Platinum Series
Normal Voltage ESC（Supports 2 to 6 Cells Lipo)
Class	Model	Cont. Current	Burst Current	BEC Mode	BEC Output	User Programmable	Battery Cells		Weight	Size
							Lipo	NiMH		L*W*H
40A	Platinum-40A	40A	60A	Switch	5.25V or 6V, 3A	Yes	2-6	5-18	38g	59*27*12
60A	Platinum-60A	60A	90A	Switch	5.25V or 6V, 3A	Yes	2-6	5-18	68g	70*34*16
80A	Platinum-80A	80A	120A	Swicth	5.25V or 6V, 3A	Yes	2-6	5-18	77g	70*34*16
100A	Platinum-100A	100A	150A	Switch	5.25V or 6V, 3A	Yes	2-6	5-18	82g	70*34*16
150A	Platinum-150A-OPTO	150A	220A	None	None	Yes	2-6	5-18	125g	88*55*15
High Voltage ESC（Supports 5 to 12 Cells Lipo)
50A	Platinum-50A-HV	50A	75A	None	None	Yes	5-12	15-36	68g	70*34*16
70A	Platinum-70A-HV	70A	105A	None	None	Yes	5-12	15-36	82g	70*34*16
100A	Platinum-100A-HV	100A	150A	None	None	Yes	5-12	15-36	123g	88*55*15
120A	Platinum-120A-HV	120A	180A	None	None	Yes	5-12	15-36	125g	88*55*15

*This ESC is OPTO version and does not have BEC output, which means you need a separate RX battery pack or external BEC unit to power the receiver and servos.

Includes:
1 x ESC
1 x English Manual
