Features:

Features:

- Supports up to 10S Lipo input.
- Dual BEC output 12V and 5.3V. 12V output for VTX or gimbal, max current 3A. 5.3V output for APM, PX4, PIXHAWK flight control.
- Comes with voltage and current (VI) sensor 6-pin port, can connect to PM port of APM, PX4 and PIXHAWK flight controllers directly.
- Support up to 8 ESCs, adopts heavy duty PCB,  can support up to 120A current.

Specifications:

Power Distribution Board W/ Dual BEC, Voltage/Current Sensor Port for PIXHAWK PX4 APM

Max ESC number: 8
Power input:  max 10S Lipo
BEC output: 5.3V / 12V
BEC output current: 3A max
Main PCB Max current capacity: 120A
Weight: 20g
Dimension: 50 x 50 x 7mm

Includes/Requires:

Includes:
1 x wiring hub
