    Hobbywing Platinum 120A Speed Control V5
    SKU PLT120AV5
    Brand HOBBYWING
    Added 2024/08/06
    Updated 2024/08/06

    Tags: Hobbywing_Platinum_120A_Speed_Control_V5

    Features:


    Specifications:

    Hobbywing Platinum 120A Speed Control V5


    Product Name
    Platinum 120A V5
    Product Number
    30203402
    Type
    Brushed/BrushlessBL
    High Voltage/RegularRegular
    Specifications
    Cont./Peak Current120A/150A
    Input Voltage3-8S Lipo
    BEC OutputSwitch Mode:5-12V & Cont. 10A，Peak 30A
    Wires & Connectors
    Input WiresRed-10AWG-150mm*1/Black-10AWG-150mm*1
    Output WiresBlack-12AWG-100mm*3
    Input ConnectorsNo
    Output Connecotors4.0mm Gold Connectors (Female)
    ESC Programing via
    TransmitterNot Support
    LED Program CardNot Support
    LED Program BoxNot Support
    LCD Program BoxSupported
    OTA ProgrammerSupported
    Program PortSeparate Program Port
    Firmware
    Firmware UpgradeSupported
    Telemetry Function
    Mikado VBar；Futaba S.Bus2；etc.
    Size & Weight
    Size83.2*37.1*22.5mm(without fan)
    Weight150.4g(with wires, no fan)
    Application scope
    420-520 class electric helicopter (main blade length 420-520mm),or fixed-wing

    Includes/Requires:

    Includes:
    1 x  Hobbywing Platinum 120A Speed Control V5 ESC
