| SKU | TORO150 |
|---|---|
| Brand | SKYRC |
| Manual | Manual 1 |
| Added | 2011/06/11 |
| Updated | 2011/06/11 |
Features:
Controls, TORO 8 | Fwd/Brk or Fwd/Brk/Rev |
Input Power (Cells) | (2-6S LiPo) |
Motor Limits, TORO 8 Brushless KV 2400 Brushless KV 2400 | Up to 6S(25.2Volt), for 1/8 monster trucks and truggies Up to 4S(16.8Volt), ideal for 1/8 buggies |
On Resistance,Brushless | 0.0002 Ohms per phase at 25 C (77 F) Trans. Temp. |
Continuous/Burst Current | 150 Amp / 950 Amp |
Switching BEC | 5.7 Volts, 3 Amp |
Status LED | 1 with 3 color (Red, Green & Orange) |
Thermal Overload Protection | Yes |
Dimensions(LxWxH) | 48.8x57.8x35.8mm (1.29x2.28x1.41in) |
Weight (Without wires) | 88g (3.1oz) |
Specifications:
Speed control specifications:Input Power (Cells): 2-6S LiPo
Motor Limits
Brushless KV≤2400: Up to 6S(25.2Volt),
for 1/8 monster trucks and truggies
Brushless KV>2400: Up to 4s(16.8volt)
ideal for 1/8 buggies
Continuous/Burst Current: 150 Amp / 950 Amp
Dimension: 48.8x57.8x35.8mm
Weight (Without wires): 88g
Includes/Requires:
Includes:1 x ESC
