| SKU | 2316SL-98 |
|---|---|
| Brand | HOBBYWING |
| Added | 2024/03/06 |
| Updated | 2024/03/06 |
Specifications:
Hobbywing SKYWALKER 2316SL 980KV Airplane Brushless Motor
Manufacturer code: 30415050
Recommended Battery: 3-4S LiPO
KV: 980KV
No-load Current: 1.5A/ 14.8V
Internal resistance: 53.6mΩ
Maximum continuous current: 31A/ 240s
Maximum continuous power: 455W/ 240s
Motor Size: Φ28.8 x 50mm
Shaft Diameter: 4mm
Clip mounting hole thread: Φ12mm-3xM2.5
Base thread: Φ16mm-2xM3/Φ19mm-2xM3
Motor Weight: 79g
Recommend configuration (not included):
ESC: Skywalker-V2 30A - 40A
propeller:
3S：10x6E，11x5.5E
4S：9x4.5E，9x6E，10x5E
Recommended Battery: 3-4S LiPO
KV: 980KV
No-load Current: 1.5A/ 14.8V
Internal resistance: 53.6mΩ
Maximum continuous current: 31A/ 240s
Maximum continuous power: 455W/ 240s
Motor Size: Φ28.8 x 50mm
Shaft Diameter: 4mm
Clip mounting hole thread: Φ12mm-3xM2.5
Base thread: Φ16mm-2xM3/Φ19mm-2xM3
Motor Weight: 79g
Recommend configuration (not included):
ESC: Skywalker-V2 30A - 40A
propeller:
3S：10x6E，11x5.5E
4S：9x4.5E，9x6E，10x5E
Includes/Requires:
Includes:1 x motor Skywalker 2316SL
1 x accessory bag
