Super Light 5.8G 200mW 32Ch Transmitter (6.7g only, 2-7S input) FT952
    SKU FT-952
    Added 2014/07/01
    Updated 2014/09/02
    Tags: video  recording  system,  FPV  mini  super  light  FPV  AV  tansmitter  32  channel


    Special features:
    - 32 channels, compatible with most receivers available on market.
    - super light,  6.7g only.
    - 2-7S Wide input voltage range.

    Designed for mini quadcopters etc.


    Super Light 5.8G 200mW  32Ch Transmitter (6.7g only, 2-7S input) FT952

    Whole system weight: 12g (including wire);  10g excluding wire
    video format supported: NTSC/PAL/SECAM (auto)
    Power input: 2-7S/ 6-30V
    Transmitting current: 110mA @ 12V;
    Transmitting power: 200mW
    Antenna connector: SMA, jack (module side)
    Wiring definition:  black for GND (power and video);  Red for Positive; White for audio, Yellow for video
    Dimension: 41 x 21 x 10mm


    1 x transmitting unit (TX)
    1 x 4-pin cable
    1 x 5.8G 2db antenna
