| SKU | 58G94DB |
|---|---|
| Brand | LANTIAN |
| Added | 2017/12/20 |
| Updated | 2017/12/20 |
Specifications:
LANTIAN 5.8G Pagoda Pro 9.4 dBi High Gain Antenna Panel SMA Female (with SMA Male to RP-sma Male Adapter)
Specifications:
Model: LANTIAN-pagoda-pro
Center frequency: 5.8 GHz
Bandwidth: 660 MHz (5.47 – 6.13 GHz)
Matching: S11 andlt; -20 dB, VSWR andlt; 1.22 (at center frequency)
Axial ratio: andlt; 1.3
Antenna gain: 9.4 dBi
Half power beam width: 55° (horizontal and vertical)
Radiation efficiency: 83.5%
Size: 5cm x 5cm x 2cm
Weight:10.06g
Includes/Requires:
Includes:1x Connector Cable
1 x Antenna
