Specifications:

Channels: 8
Operating temp: -10~85 ℃
Audio frequency: 6.5 MHz
Video input impedance: 75 Ohm
Audio input impedance: 10K/Ohm
Antenna connection: RP-SMA  jack (module side)   Refer to here for connector type diagram
Channels 5.8G : 5705,5685,5665,5645,5885,5905,5925,5945 MHZ
Receiver operating voltage: 7.4~12.6 V DC
Video bandwidth: 0~8.0 MHz
Video input level: 0.8~1.2 Vp-p
Audio input level: 0.5~2.0 Vp-p
Weight: 43 g
Dimensions: 61x52x13 mm

Includes/Requires:

Includes:
1 x transmitting unit
1 x basic wires
