| SKU | Z15BMPC |
|---|---|
| Brand | DJI |
| Added | 2015/04/20 |
| Updated | 2015/04/20 |
Specifications:
DJI Zenmuse Z15 BMPCC Gimbal For Blackmagic Pocket Camera & DJI S1000 S900 S800
| Supported Camera | Panasonic DMC-GH3 |
| Supported Lens | Olympus M.ZUIKO Digital ED 12mm f/2.0 |
| Control Requirements | At least 4 spare receiver channels S-Bus/PPM receiver supported |
| Software Requirements | For Assistant Software: Windows 8, 7, XP SP3 -- 32 or 64-bit |
| Working Current | Static Current: 200 mA at 25 V Dynamic Current: 400 mA at 25 V Locked-Rotor Current: 4 A at 25 V |
| GCU BEC Output | 10 A at 12 V |
| Transmit Power | GCU Wireless Video Transmission: 1 A at 12 V |
| Controlled Angle Accuracy | ±0.01° |
| Maximum Controlled Rotation Speed | Pan Axis: ±130°/s Tilt Axis: ±130°/s Roll Axis ±30°/s |
| Controlled Rotation Range | Pan Axis Control: ±360° continuous rotation Tilt Axis Control: +50 to -140° Roll Axis Control: ±40° |
| Power Requirements | GCU: 4S to 12 S LiPo (6S if using S800) |
| Operating Temperature | 14 to 122°F (-10 to 50°C) |
| Dimensions | Gimbal: 9 x 8.3 x 8.3" (227 x 212 x 210 mm) GCU: 2.5 x 1.4 x 0.8" (64.2 x 34.1 x 19.5 mm) |
| Weight | Gimbal: 2.9 lb (1.3 kg) GCU: 2.2 oz (63 g) |
Includes/Requires:
Includes:1x DJI Zenmuse Z15 BMPCC Gimbal
* This is the gimbal only, Camera or drone are NOT included.
